Optimization strategy of solid state laser

Optimization strategy of solid state laser
Optimizing solid-state lasers involves several aspects, and the following are some of the main optimization strategies:
一, The optimal shape of the laser crystal selection: strip: large heat dissipation area, conducive to thermal management. Fiber: large surface area to volume ratio, high heat transfer efficiency, but pay attention to the force and installation stability of the fiber. Sheet: The thickness is small, but the force effect should be considered when installing. Round rod: the heat dissipation area is also large, and the mechanical stress is less affected. Doping concentration and ions: Optimize the doping concentration and ions of the crystal, fundamentally change the absorption and conversion efficiency of the crystal to the pump light, and reduce heat loss.
二, Thermal management optimization heat dissipation mode: immersed liquid cooling and gas cooling are common heat dissipation modes, which need to be selected according to the specific application scenario. Consider the material of the cooling system (such as copper, aluminum, etc.) and its thermal conductivity to optimize the heat dissipation effect. Temperature control: The use of thermostats and other equipment to keep the laser in a stable temperature environment to reduce the impact of temperature fluctuations on laser performance.
三, The optimization of pumping mode pumping mode selection: side pump, Angle pump, surface pump and end pump are common pumping modes. The end pump has the advantages of high coupling efficiency, high conversion efficiency and portable cooling mode. Side pumping is beneficial for power amplification and beam uniformity. Angle pumping combines the advantages of face pumping and side pumping. Pump beam focusing and power distribution: Optimize the focus and power distribution of the pump beam to increase pumping efficiency and reduce thermal effects.
四, The optimal resonator design of the resonator and the output coupling: select the appropriate reflectivity of the cavity mirror and the cavity length to achieve the multi-mode or single-mode output of the laser. The output of single longitudinal mode is realized by adjusting the cavity length, and the power and wavefront quality are improved. Output coupling optimization: Adjust the transmittance and position of the output coupling mirror to achieve high efficiency output of the laser.
五, Material and process optimization Material selection: According to the application needs of the laser to select the appropriate gain medium materials, such as Nd:YAG, Cr:Nd:YAG, etc. New materials such as transparent ceramics have the advantages of short preparation period and easy high concentration doping, which deserve attention. Manufacturing process: The use of high-precision processing equipment and technology to ensure the processing accuracy and assembly accuracy of the laser components. Fine machining and assembly can reduce errors and losses in the optical path and improve the overall performance of the laser.
六, Performance evaluation and testing Performance evaluation indicators: including laser power, wavelength, wave front quality, beam quality, stability, etc. Test equipment: Use optical power meter, spectrometer, wave front sensor and other equipment to tes`t the performance of the laser. Through testing, the problems of the laser are found in time and the corresponding measures are taken to optimize the performance.
七, Continuous innovation and technology Tracking technological innovation: pay attention to the latest technological trends and development trends in the laser field, and introduce new technologies, new materials and new processes. Continuous improvement: Continuous improvement and innovation on the existing basis, and constantly improve the performance and quality level of lasers.
In summary, the optimization of solid-state lasers needs to start from many aspects, such as laser crystal, thermal management, pumping mode, resonator and output coupling, material and process, and performance evaluation and testing. Through comprehensive policies and continuous improvement, the performance and quality of solid-state lasers can be continuously improved.
